Foam Sponge Automatic Mattress Spraying Machine for Bedding

Designed to create foam encased units and/or adhere quilted mattress panels.Features a hot melt adhesive with either a spin-spray or bead application.Gluing heads oscillate left and right while applying adhesive and provide controllable application of adhesives,adjustable speed gluing application,and silicone laminated conveyor or belts with cleaning rollers,without manually adjusting and positioning.
Adopts PLC control system,can be connected mattress production line.Advance Switzerland Robatech Brand adhesive melter.Conveyor belt guides ensure accurate tracking.Ergonomic design and operator friendly.Low loss,low cost .
Spraying machine can work with centering assembly ,liftable table and presser be a whole line.

Model:
YK-HG-3
Brand:
YIKAI

Availability:

Quantity:



Inquire Add to Basket

Product Description

Centering assembly
Oversize	(L)2500(W)2200mm(H)1000

Hotmelt spraying machine
ROBATECH Hot melter	30KGS
Feeding width	1600-2100mm;
Feeding thickness	10-100mm/150-400mm
Spraying heads	4 groups or 5 gropus
Capacity	15 Seconds/side(1800*2000mm)
Working temperature	+5℃--+45℃;
Air Pressure	0.6mpa
Total power	8Kw
Power supply	380V 3phase 50/60hz

微信图片_20211209144940

微信图片_20211210094926

automatic Mattress Spraying Machine Mattress Spraying Machine for Bedding automatic Mattress Spraying Machine for Bedding foam sponge Mattress Spraying Machine foam sponge Mattress Spraying Machine for Bedding automatic foam sponge Mattress Spraying Machine automatic foam sponge Mattress Spraying Machine for Bedding
